Bitbox

Toyota Denso NEC 76F00XX (FID: 24)

Toyota Denso NEC TCM 76F00XX (FID: 26) — test

NEC 76F0038, 76F0039, 76F0040, 76F0070 and 76F0085

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

Module for OBD virtual reading and writing with CAN-bus Toyota Denso and Fujitsu Ten Gen1 ECUs used in Toyota/Lexus/Scion/Hino petrol and diesel vehicles.

Toyota Denso NEC 76F00XX (FID: 24)

Toyota Denso NEC TCM 76F00XX (FID: 26) - test

It supports working with ECM and TCM of Denso ECUs with CAN-bus and based on MCUs NEC 76F0038, 76F0039, 76F0040, 76F0070, 76F0085.

Features of Module:

- Software identification
- Virtual reading lastest software update
- Writing (update version or downgrade)
- Checksums and CVN correction
- Recovery from any state*

* This feature allows to recovery ECU damage (with any tool) during CANBus writing or while Techstream update. You don't need any NBD/JTAG device, it CAN BE DONE with J2534 device via CANBus with bootstrap mode. This feature allows easy recovery of ECUs, including LC200 4.5TD without hard opening of the case and neccessary access to back side of PCB, and also new ECUs without NBD/JTAG pins on PCB (for example Camry V50, Highlander 3.5 U50, etc.).

Type 1:

Engine MCU D76F0199GD 1280Kb

Engine MCU D76F0196F1 1536Kb

Engine MCU D76F0219F1 2048Kb

Transmission MCU D76F0199GD 1280Kb

Transmission MCU D76F0196F1 1536Kb

Type 2:

Engine MCU D76F0199GD 1280Kb

Engine MCU D76F0196F1 1536Kb

Engine MCU D76F0198F1 1536Kb

Engine MCU D76F0219F1 2048Kb

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

Module for OBD reading/virtual reading and writing Toyota Denso newGen ECUs used in Toyota&Lexus petrol and diesel vehicles. Checksum correction included.

Module supports 2 protocols types:

TYPE 1 (FID: 23, 27)

Allowed FullFlash READING and WRITING Toyota&Lexus petrol vehicles with 2.0 6ARFSE, 2.0T 8ARFTS, 1.2T 8NRFTS, 3.5 2GRFKS, 3.5 7GRFSE etc. engines via P5-CAN-bus.

• Engine MCU D76F0199GD 1280Kb
• Engine MCU D76F0196F1 1536Kb
• Engine MCU D76F0219F1 2048Kb
• Transmission MCU D76F0199GD 1280Kb
• Transmission MCU D76F0196F1 1536Kb

Also this FID allows to set READ PROTECTION PATCH which will disable ECU reading and will protect your MOD files from stole.

Supported vehicles:

Lexus NX 200t AGZ1#
Lexus IS 200t ASE30
Lexus GS 200t ARL10
Lexus RX 200t AGL2#
Lexus RC 200t ASC10
Lexus ES 200 ASV61
Toyota Auris 1.2t NRE185
Toyota Camry 2.0 ASV51
Toyota Crown 2.0t
Toyota Tacoma 3.5 GRN3##
Lexus GS 350 GRL1#
Lexus RX 350 GGL2#
Toyota Highlander 2.0t ASU5#
Toyota C-HR 1.2t NGX##

Supported engines:

2.0 6AR-FSE
2.0 8AR-FTS
1.2 8NR-FTS
3.5 2GR-FKS
3.5 7GR-FSE
3.5hyb 8GR-FXS
1.8hyb 2ZR-FXE
etc...

TYPE 2 (FID: 28)

Allowed FullFlash VIRTUAL READING and WRITING with CS and CVN correction for Toyota&Lexus diesel and NA petrol vehicles with 2.8TD 1GDFTV, 2.4TD 2GDFTV, 4.0 1GRFE, 2.7 2TRFE, 2NRFE, 3ZRFAE engines. Writing possible ONLY if we have file for your vehicle on our server.

• Engine MCU D76F0199GD 1280Kb
• Engine MCU D76F0196F1 1536Kb
• Engine MCU D76F0198F1 1536Kb
• Engine MCU D76F0219F1 2048Kb

Supported vehicles:

Toyota C-HR ZGX10L

Toyota HiLUX GUN##

Toyota LC150 Prado GDJ##, GRJ15#

Toyota Tacoma TRN2##

Toyota Yaris 1.5 NSP151

Lexus RC-F USC10

Lexus GS-F URL10

Lexus RX450h GYL2#

Supported engines:

2.8TD 1GDFTV
2.4TD 2GDFTV
4.0 1GRFE
2.7 2TRFE
5.0 2URGSE
1.5 2NRFE
2.0 3ZRFAE
2.5 2ARFE
etc...

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

Module for OBD reading and writing with CAN-bus Toyota Denso and Fujitsu Ten Gen3 ECUs used in Toyota/Lexus petrol and diesel vehicles with new Dynamic Force engines.

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

Toyota Gen1 ECM Virtual reader

Toyota Denso Gen1 TCM Virtual reader

Toyota Denso Gen1 HCM Virtual reader

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

D76F0199GD 1280Kb

D76F0196F1 1536Kb

D76F0198F1 1536Kb

D76F0219F1 2048Kb

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

FID: 453

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

Package of 7 modules with discount for Toyota/Lexus/Scion/Hino vehicles.

Package includes:

- Toyota Denso Gen1 CAN

- Toyota Denso Gen2/newGen CAN

- Toyota Denso Gen3 CAN

- Toyota Denso Gen4 BENCH-CAN

- Toyota Delphi Gen1 CAN

- Toyota Gen1 Virtual Reader

- Toyota Denso Gen2 Reader

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

• Bosch EDC17CP45 (DDE7.3.1)
• Bosch EDC17CP02 (DDE7.1)
• Bosch EDC17C06 (DDE7.0)
• Bosch EDC17CP09 (DDE7.3)
• Bosch EDC17C41 (DDE7.2.1)
• Bosch EDC17C50 (DDE7.0.1)
• Bosch MEVD17.2
• Bosch MEVD17.2.6
• Bosch MEVD17.2.9

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

Bosch EDC17C41 (DDE7.2.1)

Bosch EDC17C50 (DDE7.0.1)

Bosch EDC17C56 (DDE7.4.1)

Bosch EDC17CP45 (DDE7.3.1)

Bosch EDC17CP49 (DDE7.5.1)

Bosch EDC17CP09 (DDE7.3a)

Bosch MEVD17.2

Bosch MEVD17.2.4

Bosch MEVD17.2.5

Bosch MEVD17.2.6

Bosch MEVD17.2.9

Bosch MEVD17.2.G (incl. S55)

Bosch MEVD17.2.8

Bosch MEVD17.2.H

Bosch MEVD17.2.3

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

Module for reflashing through OBD2 connector by Ethernet for Bosch ECUs used in diesel BMW Fxx vehicles. No need to dismount, open or drill an ECU - FULL OBD2 solution.

Warning! Module doesn’t work with J2534 adapter, BMW ENET-to-OBD2 cable is required for work. Also this family can’t work on the bench!

Module allows:

• Identification
• Virtual Reading
• Writing program and maps
• CS and CVN fix on writing
• Recovery with original file (as official BMW diagnostic system)
• Reading and writing coding data
• DTC reading / clearing

Supported diesel ECUs:
• Bosch EDC17C41 (DDE7.2.1)
• Bosch EDC17C50 (DDE7.0.1)
• Bosch EDC17C56 (DDE7.4.1)
• Bosch EDC17CP45 (DDE7.3.1)
• Bosch EDC17CP49 (DDE7.5.1)
• Bosch EDC17CP09 (DDE7.3a)

Supported petrol ECUs:
• Bosch MEVD17.2
• Bosch MEVD17.2.4
• Bosch MEVD17.2.5
• Bosch MEVD17.2.6
• Bosch MEVD17.2.9
• Bosch MEVD17.2.G (incl. S55)
• Bosch MEVD17.2.8
• Bosch MEVD17.2.H
• Bosch MEVD17.2.3

We will not respond to the claims about the inability to read a file from our server if we do not have it.

Module for reflashing through OBD2 connector by Ethernet for Bosch MG1 and MD1 ECUs used in BMW Fxx and Gxx vehicles.

Supports Bosch ECUs based on MCU NXP MPC5777 with 7.5Mb of main flash memory and Infineon Aurix TC298 with 8Mb memeory.

BMW Fxx/Gxx Bosch MG1 MPC5777 ENET (FID: 160)

BMW Fxx/Gxx Bosch MD1 MPC5777 ENET (FID: 161)

BMW Fxx/Gxx Bosch MG1 TC298 ENET (FID: 162) [TEST]

Module allows:

Software identification
Virtual reading from server
Reading if file not found in server (not for all SW versions)
Writing with checksumm and CVN correction
DTC read and clear

Please read about limited support for vehicles with newest firmware versions.

BMW Continental MSD8X TC1796 BENCH-CAN

BMW Continental MSV80 TC1796 BENCH-CAN

BMW Continental MSV90 TC1796 BENCH-CAN

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

FIDs: 335, 336, 412

Module for reflashing on the BENCH by CAN-bus Continental ECUs used in BMW petrol vehicles.

BMW Continental MSD8X TC1796 BENCH-CAN (FID:335)

Engine control units are based on MCU Infineon Tricore TC1796 with internal flash memory 2.0 Mb. Allows read/write/CS on the BENCH. At this moment it supports MSD80, MSD81, MSD85, MSD87 ECU types.

BMW Continental MSV80 TC1796 BENCH-CAN (FID:412)

Engine control units are based on MCU Infineon Tricore TC1796 with internal flash memory 2.0 Mb. Allows read/write/CS on the BENCH.

BMW Continental MSV90 TC1796 BENCH-CAN (FID:336)

Engine control unit is based on MCU Infineon Tricore TC1796 with internal flash memory 2.0 Mb. Allows read/write/CS on the BENCH.

Module does not allow ECU clonning.

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

Package of all 3 modules we have for BMW with discount. BMW Bosch Exx CAN + Fxx Bosch ENET + Fxx/Gxx Bosch MG1/MD1 ENET.

• Bosch EDC17CP01 / EDC17CP10
• Bosch EDC17CP57 / EDC17CP60 / EDC17C66
• Bosch EDC17CP46
• Bosch EDC17C43

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

FID: 200, 201, 202

Module for reading and writing through the diagnostic connector by CAN-bus for diesel Mercedes-Benz vehicles with Bosch EDC17 ECUs.

Supported ECU types:

• Bosch EDC17CP01 / EDC17CP10 (FID: 200)
• Bosch EDC17CP57 / EDC17CP60 / EDC17C66 (FID: 201)
• Bosch EDC17CP46 (FID: 202)
• Bosch EDC17C43 (FID: 206)

Attention! Bosch EDC17CP01 with no ext. flash is not supported.

Module allows:

• SW identification
• Reading of calibration area
• Writing of calibration area
• CS correction

• MB Bosch MED17.7.1 / MED17.7.3
• MB Bosch MED17.7.3.1
• MB Bosch MED17.7.2
• MB Bosch MED17.7.5
• Infiniti Bosch MED17.7.2

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

FID: 203, 204, 205, 208

Module for virtual reading and writing through the diagnostic connector by CAN-bus for petrol Mercedes-Benz vehicles with Bosch MED17 ECUs.

Supported ECU types:

• MB Bosch MED17.7.1 / MED17.7.3 (FID: 205)
• MB Bosch MED17.7.3.1 (FID: 204)
• MB Bosch MED17.7.2 (FID: 203)
• MB Bosch MED17.7.5 (FID:215)
• Infiniti Bosch MED17.7.2 (FID: 208)

Module allows:

• SW identification
• Virtual Reading of calibration area (900+ files in a base)
• Writing of calibration area
• CS correction

Continental SIM271DE2.0

Siemens SIM271KE2.0

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

MB Delphi CRD3.xx TC1797

MB Delphi CRD3.xx TC1793

MB Delphi CRD3.xx TC1793 BENCH

Infiniti Delphi CRD3.xx

MB Delphi CRD2.xx

MB Delphi CRD.11

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

FIDs: 197, 214, 216, 217, 218, 254

Module for reading and writing through the diagnostic connector by CAN-bus for diesel Mercedes-Benz vehicles with Delphi CRD ECUs.

MB Delphi CRD3.xx TC1797 (FID: 214)

This FID is for working with Delphi CRD3.xx ECUs based on Infineon Tricore TC1797 with internal flash memory 4 Mb.

Allows reading and writing with checksumm correction by CANbus.

MB Delphi CRD3.xx TC1793 (FID: 197)

This FID is for working with Delphi CRD3.xx ECUs based on Infineon Tricore TC1793 with internal flash memory 4 Mb.

Allows reading and writing with checksumm correction by CANbus.

Attention! We strongly recommend to write this ECUs on the BENCH. Writing by OBD2 on vehicle can damage EEPROM in some cases.

MB Delphi CRD3.xx TC1793 BENCH (FID: 254)

FID for BENCH working for 2020 vehicles with Delphi CRD3.xx ECUs based on Infineon Tricore TC1793 with internal flash memory 4 Mb.

Allows reading and writing with checksumm correction by CANbus on the BENCH. Required DrewTech CarDAQ+, Scanmatik SM2 Pro or other J2534 device supported 800 kbit/s CAN.

Infiniti Delphi CRD3.xx (FID: 218)

This FID is for working with Delphi CRD3.xx ECUs based on Infineon Tricore TC1797 with internal flash memory 4 Mb.

Allows reading of calibration area and writing with checksumm correction by CANbus.

MB Delphi CRD2.xx (FID: 217)

This FID is for working with Delphi CRD2.xx ECUs based on MPC5566 with internal flash memory 3 Mb.

Allows reading and writing with checksumm correction by CANbus.

MB Delphi CRD.11 (FID: 216)

This FID is for working with Delphi CRD.11 ECUs based on MPC563 with external flash memory with total 2.5 Mb.

Allows reading and writing with checksumm correction by CANbus. If you have OBD writing issue - connect ECU on the bench.

• Motorola NGC3 MPC565 1Mb (FID: 12)
• Motorola NGC4 MPC5554 2Mb (FID: 13)
• Motorola NGC4A MPC5554 2Mb (FID: 15)
• Continental GPEC (SIM90) MPC561+EXT.FLASH 2Mb (FID: 16) - calibration only
• Continental GPEC2 MPC5566 3Mb (FID: 14)

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

Continental GPEC2 2013+ MPC5566 3Mb (FID: 20)

Continental GPEC2 2015+ MPC5566 3Mb (FID: 21)

Continental GPEC2A MPC5674 4Mb (FID: 19)

Continental GPEC2A 2018+ MPC5674 4Mb (FID: 131)

Continental GPEC3 MPC5674 4Mb (FID: 18)

Continental GPEC2 MPC5566 CAN BSL (FID: 319)

Continental GPEC2A/GPEC3 MPC5674 CAN BSL (FID: 320)

Continental GPEC4/GPEC4LM MPC5674 CAN BSL (FID: 321)

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

• FCA Bosch EDC17C49 (FID: 106)
• FCA Bosch EDC17C79 (FID: 107)
• FCA Bosch EDC17CP27 (FID: 108)
• FCA Bosch EDC17C49/C79 Reader (FID: 124)

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

SsangYong Delphi DCM6.2AP (FID: 32)

SsangYong Delphi DCM6.2AP-6D (FID: 87)

SsangYong Delphi DCM3.7AP (FID: 33)

SsangYong Delphi DCM3.2AP (FID: 35)

SsangYong Delphi DCM3.1 (FID: 34)

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

Siemens SIM2K-410 (FID: 40)

Siemens SIM2K-C201 (FID: 45)

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

FID: 40, 45

Kia/Hyundai Denso Diesel SH72546 (FID: 42)

Kia/Hyundai Delphi DCM6.2AP (FID: 41)

Kia/Hyundai Delphi DCM6.2AP BSL (FID: 343)

Kia/Hyundai Delphi DCM3.7AP (FID: 39)

Kia Delphi DCM3.2AP (FID: 37)

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

Kefico CPEGD2.20.1/CPGDSH2.26.1 (FID: 70)

Bosch ME(G)17.9.1x (FID: 72)

Bosch ME(G)17.9.21 (FID: 74)

Bosch ME(D)(G)17.9.8 (FID: 73)

Siemens SIM2K-47 (FID: 88)

Siemens SIM2K-24x (FID: 93)

Siemens SIM2K-141/341 (FID: 104)

Siemens SIM2K-141.1 (FID: 144)

Delphi MT86 (FID: 77)

Kefico M(E)(G)7.9.8 (FID: 368)

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

Continental SIM2K-25x TC1782 CAN (FID: 152)

Continental SIM2K-26x TC1791 CAN (FID: 252)

Continental SIM2K-25x TC1782 BSL (FID: 150)

Continental SIM2K-26x TC1791 BSL (FID: 151)

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

Kia/Hyundai Kefico CPGDSH2.2x.x/CPEGD2.20.x (FID: 251)

Kia/Hyundai Kefico CPGDSH2.2x.x/CPEGD2.20.x BSL (FID: 253)

Kia/Hyundai Kefico CPGPSH2.14.1/CPEGP2.10.1 (FID: 303)

Kia/Hyundai Kefico CPGPSH2.14.1/CPEGP2.10.1 BSL (FID: 304)

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

FID: 251, 253, 303, 304

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

FIDs: 365, 366, 367, 371, 373, 436, 438, 439, 440, 441, 442, 443, 445, 449, 451

Module for reading and writing with CAN-bus Delphi ECUs used in diesel vehicles from Indian market.

Allows to get Software ID, read, write and CS fix.

• Tata Delphi DCM2.5 XC2XXX CAN (FID: 365)
• Tata Delphi DCM2.5P XC2XXX CAN (FID: 366)
• Mahindra Delphi DCM2.5 XC2XXX CAN (FID: 367)
• Mahindra Delphi DCM2.7AP MPC5642 CAN (FID: 371)
• Eicher Delphi DCM2.7AP MPC5643 CAN (FID: 449)
• Ashok Leyland Delphi DCM2.5 XC2XXX CAN (FID: 373)
• Tata Delphi DCM3.7AP SH72543/SH72544 (FID: 451) - VR/W/CS
• Mahindra Delphi DCM7.1AP TC277T CAN (FID: 438)
• Tata Delphi DCM7.1AP TC277T CAN (FID: 439)
• Kia/Hyundai Delphi DCM7.1AP TC277T CAN (FID: 440)
• Ashok Leyland Delphi DCM7.1AP TC277T CAN (FID: 441)
• Eicher Delphi DCM7.1AP TC277T CAN (FID: 443)
• Force Motors Delphi DCM7.1AP TC277T CAN (FID: 442)
• Tata Delphi DCM7.24 TC277T CAN (FID: 445)
• Mahindra/Eicher/Force Motors Delphi DCM2.7AP MPC564X BSL (FID: 436)***

*** - for BSL it needs to use SM2 or CarDAQ.

Ford Bosch MG1CS015/MG1CS016 TC277 (FID: 180)

Ford Bosch MG1CS017/MG1CS018/MG1CS019 TC298 (FID: 181)

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

FID: 180, 181

Module for reading and writing through the diagnostic connector Ford petrol vehicles with Bosch MG1 ECUs

Ford Bosch MG1CS015/MG1CS016 TC277 (FID: 180)

This FID is for working with Bosch MG1CS015 ECUs based on Infineon Aurix TC277 with internal flash memory 4Mb.

Allows reading and writing with checksumm correction by CANbus.

Ford Bosch MG1CS017/MG1CS018/MG1CS019 TC298 (FID: 181)

This FID is for working with Bosch MG1CS017, MG1CS018 and MG1CS019 ECUs based on Infineon Aurix TC298 with internal flash memory 8Mb.

Allows reading and writing with checksumm correction by CANbus.

Ford Continental SID206 (FID: 259)

Ford Continental SID208 (FID: 255)

Ford Continental SID209 (FID: 279)

Ford Continental SID211 (FID: 256)

Ford Continental SID803 (FID: 260)

Ford Continental SID803A (FID: 261)

Ford Continental SID807EVO (FID: 257)

Ford Continental SID802 (FID: 263)

Ford Continental SID804 (FID: 262)

Ford Continental SID902 (FID: 258)

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

FIDs: 255, 256, 257, 258, 259, 260, 261, 262, 263, 279

Module for reading and writing Ford diesel vehicles with Continental SIDxxx ECUs.

Work is possible with OBD2 or on the Bench.

Ford Continental SID206 (FID: 259)

This FID is for working with Continental SID206 ECUs based on MPC561 with external flash memory 2Mb.

Allows reading and writing of calibration area with checksumm correction by CANbus.

Ford Continental SID208 (FID: 255)

This FID is for working with Continental SID208 ECUs based on Infineon Tricore TC1797 with internal flash memory 4Mb.

Allows FullFlash reading / writing of calibration area with checksumm correction by CANbus.

Ford Continental SID209 (FID: 279)

This FID is for working with Continental SID209 ECUs based on Infineon Tricore TC1797 with internal flash memory 4Mb.

Allows FullFlash reading / writing of calibration area with checksumm correction by CANbus.

Ford Continental SID211 (FID: 256)

This FID is for working with Continental SID211 ECUs based on Infineon Tricore TC1791 with internal flash memory 4Mb.

Allows FullFlash reading / writing of calibration area with checksumm correction by CANbus.

Ford Continental SID803 (FID: 260)

This FID is for working with Continental SID803 ECUs based on MPC561 with internal flash memory 448Kb.

Allows reading and writing of calibration area with checksumm correction by CANbus.

Ford Continental SID803A (FID: 261)

This FID is for working with Continental SID803A ECUs based on MPC561 with external flash memory 2Mb.

Allows reading and writing of calibration area with checksumm correction by CANbus.

Ford Continental SID807EVO (FID: 257)

This FID is for working with Continental SID807EVO ECUs based on Infineon TC1797 with internal flash memory 4Mb.

Allows reading and writing of calibration area with checksumm correction by CANbus.

Ford Continental SID802 (FID: 263)

This FID is for working with Continental SID802 ECUs based on Infineon C167 with external flash memory 512Kb.

Allows reading and writing of calibration area with checksumm correction by CANbus.

Ford Continental SID804 (FID: 262)

This FID is for working with Continental SID804 ECUs based on Infineon C167 with external flash memory 512Kb.

Allows reading and writing of calibration area with checksumm correction by CANbus.

Ford Continental SID902 (FID: 258)

This FID is for working with Continental SID902 ECUs based on Infineon MPC563 with external flash memory 2Mb.

Allows reading and writing of calibration area with checksumm correction by CANbus.

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

FIDs: 265, 266, 267, 268, 269, 270, 271, 272, 273, 274, 275, 276, 330, 339, 342, 372

Module for reading and writing by CANbus Ford petrol vehicles with Continental EMSxxxx ECUs.

• Ford Continental EMS2101/EMS2103/EMS2106 C167+Ext.Flash 1MB CAN - R/W/CS
• Ford Continental EMS2102 C167+Ext.Flash 512KB CAN - R/W/CS
• Ford Continental EMS2204 TC1738 2MB CAN - R/VR/W/CS/VBF to BIN
• Ford Continental EMS2205 TC1766 1.46MB CAN - R/VR/W/CS/VBF to BIN
• Ford Continental EMS2207 TC1738 2MB CAN - R/VR/W/CS/VBF to BIN
• Ford Continental EMS2208 TC1767 2MB CAN - R/VR/W/CS/VBF to BIN
• Ford Continental EMS2209 TC1767 2MB CAN - R/VR/W/CS/VBF to BIN
• Ford Continental EMS2211 TC1738 2MB CAN - R/VR/W/CS/VBF to BIN
• Ford Continental EMS2212/EMS2213/EMS2214/EMS2215 TC1738 2MB CAN - R/VR/W/CS/VBF to BIN
• Ford Continental EMS2219 TC1738 2MB CAN - R/VR/W/CS/VBF to BIN
• Ford Continental EMS2301/EMS2302 TC1724 1.5MB CAN - R/W/CS
• Ford Continental EMS24xx TC1791 4MB CAN - R/VR/W/CS/VBF to BIN
• Ford Continental EMS2510/EMS2511/EMS2513 TC1791 4MB CAN - R/VR/W/CS/VBF to BIN
• Ford Continental EMS2701 TC1791 4MB CAN - R/VR/W/CS/VBF to BIN
• Ford Continental eSys CBP-A2 MPC5554 2MB CAN - R/W/CS
• Ford Continental eSys CBP-C2 MPC5554 2MB CAN - R/W/CS

Ford Delphi DCM3.5 (FID: 301)

Ford Delphi DCM6.1 (FID: 302)

Ford Visteon DCU-10x/DCU-20x (FID: 318)

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

FIDs: 301, 302, 318

Module for reading and writing by CANbus Ford diesel vehicles with Delphi ECUs.

Ford Delphi DCM3.5 (FID: 301)

This FID is for working with Delphi DCM3.5 ECUs based on MPC5566 with internal flash memory 3Mb.

Allows reading and writing of calibration area with checksum correction by CANbus.

Ford Delphi DCM6.1 (FID: 302)

This FID is for working with Delphi DCM6.1 ECUs based on TC1797 with internal flash memory 4Mb.

Allows reading and writing of calibration area with checksum correction by CANbus.

Ford Visteon DCU-10x/DCU-20x (FID: 318)

This FID is for working with Visteon DCU-101/102/104/201 ECUs based on ST10F276 with internal flash memory 896Kb.

Allows reading and writing with checksum correction by CANbus.

Ford Bosch MED17.0 (FID: 322)

Ford Bosch MED17.0.1 (FID: 323)

Ford Bosch MED17.0.7 (FID: 323)

Ford Bosch MEDG17.0 (FID: 323)

Ford Bosch ME17.0.3 (FID: 333)

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

FIDs: 322, 323, 324, 325, 333

Module for reading and writing Ford petrol vehicles with Bosch MED(G)17 ECUs.

Work is possible with OBD2 or on the Bench.

Ford Bosch MED17.0 (FID: 322)

This FID is for working with Bosch MED17.0 ECUs based on Infineon Tricore TC1767 with internal flash memory 2Mb.

Allows reading and writing with checksums correction by CANbus.

Ford Bosch MED17.0.1 (FID: 323)

This FID is for working with Bosch MED17.0.1 ECUs based on Infineon Tricore TC1767 with internal flash memory 2Mb.

Allows reading and writing with checksums correction by CANbus.

Ford Bosch MED17.0.7 (FID: 323)

This FID is for working with Bosch MED17.0.7 ECUs based on Infineon Tricore TC1782 with internal flash memory 2.5Mb.

Allows reading and writing with checksums correction by CANbus.

Ford Bosch MEDG17.0 (FID: 323)

This FID is for working with Bosch MEDG17.0 ECUs based on Infineon Tricore TC1797 with internal flash memory 4Mb.

Allows reading and writing with checksums correction by CANbus.

Ford Bosch ME17.0.3 (FID: 333)

This FID is for working with Bosch ME17.0.3 ECUs based on Infineon Tricore TC1724 with internal flash memory 1.5Mb.

Ford Bosch ME9.0 (FID:327)

Ford Bosch ME9.8 (FID:331)

Ford Bosch ME(D)G9.8.1 (FID:327)

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

FIDs: 326, 327, 331

JLR Bosch MED17.0 (FID:328)

JLR Bosch MED17.8.31 (FID:329)

JLR Bosch MED17.9.7 (FID:332)

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

FIDs: 328, 329, 332

Module for reading and writing Jaguar/Land Rover petrol vehicles with Bosch MED17 ECUs.

JLR Bosch MED17.0 (FID:328)

This FID is for working with Bosch MED17.0 ECUs based on Infineon TC1767 with internal flash memory 2Mb.

Allows ID, reading and writing with checksums correction by CANbus.

JLR Bosch MED17.8.31 (FID:329)

This FID is for working with Bosch MED17.8.31 ECUs based on Infineon TC1797 with internal flash memory 4Mb.

Allows ID, reading and writing with checksums correction by CANbus.

JLR Bosch MED17.9.7 (FID:332)

This FID is for working with MED17.9.7 ECUs based on Infineon TC1767 with internal flash memory 2Mb.

Allows ID, reading and writing with checksums correction by CANbus.

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

Renault Continental EMS3110 (FID:139)

Renault Continental EMS3125 (FID:165)

Renault Continental EMS3155 (FID:178)

Renault Valeo V40/V42 (FID:154)

Renault Valeo V50 (FID:169)

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

FID: 139, 154, 165, 169, 178

Module for reading and writing through the diagnostic connector Renault petrol vehicles with different ECUs.

Renault Continental EMS3110 (FID:139)

This FID is for working with Continental EMS3110 ECUs based on Infineon Tricore with internal flash memory 1.46Mb.

Allows reading and writing with checksumm correction by CANbus.

Renault Continental EMS3125 (FID:165)

This FID is for working with Continental EMS3125 ECUs based on Infineon Tricore TC1782 with internal flash memory 2.5Mb.

Allows reading and writing with checksumm correction by CANbus.

Renault Continental EMS3155 (FID:178)

This FID is for working with Continental EMS3155 ECUs based on Infineon Tricore TC1782 with internal flash memory 2.5Mb.

Allows reading and writing with checksumm correction by CANbus.

Renault Valeo V40/V42 (FID:154)

This FID is for working with Valeo V40 and V42 ECUs based on Renesas SH7058 with internal flash memory 1Mb.

Allows reading and writing with checksumm correction by CANbus.

Renault Valeo V50 (FID:169)

This FID is for working with Valeo V50 ECUs based on Renesas SH72543 with internal flash memory 2Mb.

Allows reading and writing with checksumm correction by CANbus.

Other ECU types are in development and will be add ASAP.

Renault Siemens SID301 (FID:157)

Renault Continental SID305 (FID:155)

Renault Continental SID310 (FID:177)

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

FIDs: 155, 157, 177

Module Nissan Hitachi Gen1 CAN

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

FIDs: 300

Module for reading and writing by CANbus Nissan/Infiniti petrol vehicles with Hitachi Gen1 ECUs.

Nissan Hitachi SH705X/SH72XX Gen1 CAN (FID:300)

• SH705519N 512Kb
• SH705822N, SH705828N 1024Kb
• SH705927N 1536Kb
• S7253131N 1280Kb
• S7253332N 2048Kb

Allows identification, reading with auto size recognition, writing and CS correction, DTC reading and erasing.

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

FIDs: 477

Module for reading and writing by CANbus with OBD2 for Nissan and Renault petrol vehicles with Hitachi RH850 UDS ECUs.

Nissan Hitachi RH850 2MB/4MB CAN (FID:477)

• R7F701205 2MB
• R7F701202 4MB
• R7F701216 4MB

Allows identification, reading of calibration area with auto size and regions recognition, writing and CS correction, DTC reading and erasing.

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

FID: 280

Module for reading and writing by CANbus Isuzu diesel vehicles with Transtron ECUs based on Renesas SH7058, SH7059, SH72533 and SH72544.

Isuzu Transtron SH7058/SH7059/SH72533/SH72544 CAN (FID:280)

Family for Transtron ECUs based on MCUs Renesas SH7058/SH7059/SH72533/SH72544 with internal flash memory 1Mb/1.5Mb/2Mb/2.5Mb.

Allows identification, reading with auto size recognition, writing and CS correction.

Isuzu Transtron EURO4 TC265D CAN (FID:281)

Isuzu Transtron EURO5 TC277T+TC265D CAN (FID:284)

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

FIDs: 281, 284

Module for virtual reading and writing by CANbus Isuzu diesel vehicles with Transtron ECUs based on Aurix MCUs.

Isuzu Transtron EURO4 TC265D CAN (FID:281)

Isuzu Transtron EURO5 TC277T+TC265D CAN (FID:284)

Allows identification, virtual reading, writing and CS correction.

Attention! Some vehicles with gateway do not allow writing with OBD2, please use BENCH connection for writing to complete.

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

FID: 340

Module for reading and writing ECUs by CANbus used in Honda/Acura petrol vehicles.

Honda/Acura CAN (FID: 340)

Module supports ECUs based on:

• Keihin SH7058 (1MB)
• Keihin SH72543 (2MB)
• Keihin SH72546 (3.75MB)
• Keihin MPC5566 (3MB)
• Keihin TC1782 (2.5MB)
• Keihin TC275 (4MB)
• Keihin SPC564 (2MB)
• Matsushita SH7058 (1MB)
• Matsushita SH72543 (2MB)
• Panasonic SH7058 (1MB)
• Panasonic SH72543 (2MB)
• Panasonic TC179x (4MB)
• Hitachi SH72543 (2MB)
• Hitachi MPC5554 (2MB)
• Hitachi R7F701202 (4MB)
• Continental MPC5554 (2MB)

Allows reading/writing and checksums calculation with automatical detection of ECU type.

New ECU types will be added ASAP.

FID: 334

Module for reading and writing Mitsubishi MH8XXX ECUs by CANbus used in Mitsubishi Motors Corporation (MMC) petrol vehicles.

Mitsubishi MH8XXX CAN (FID:334)

Allows reading/writing and checksums calculation with automatical detection of ECU type.

We support following types:

MH8104F 512KB
MH8106F 1MB
MH8115 1.25MB
MH8611 2MB
MH8601 4MB

New ECU types will be added ASAP

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

Module for OBD reading and writing with CAN-bus Denso and Mitsubishi ECUs used in Mazda petrol vehicles with SkyActiv-G engines.

• Mazda Denso Gen3 D02 (FID: 244) with SH72543 2.0Mb - R/W/CS
• Mazda Denso Gen3 D03 (FID: 243) with SH72543 2.0Mb - R/W/CS
• Mazda Denso Gen4 D08 (FID: 249) with MPC5746 4.0Mb - R/W/CS
• Mazda Denso Gen4 D11 (FID: 247) with MPC5746 4.0Mb - VR/W/CS
• Mazda Mitsubishi Gen3 M03/M04 (FID: 240) with MH8501 2.0Mb - R/W/CS
• Mazda Mitsubishi Gen3 M09 (FID: 243) with MH8501 2.0Mb - R/W/CS
• Mazda Mitsubishi Gen4 M13/M16/M41 (FID: 248) with MPC5746 4.0Mb - R/W/CS

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

Module for OBD reading and writing with CAN-bus Denso ECUs used in Mazda diesel vehicles with SkyActiv-D engines.

• Mazda Denso Diesel Gen3 (FID: 246) with SH72543 2.0Mb - R/W/CS
• Mazda Denso Diesel Gen3 Crypto (FID: 242) with SH72543 2.0Mb - R/W/CS
• Mazda Denso Diesel Gen3 Crypto (FID: 245) with SH72546 3.75Mb - R/W/CS
• Mazda Denso Diesel Gen4 (FID: 238) with MPC5746 4.0Mb - R/W/CS

PSA Delphi DCM6.2A (FID: 179)

PSA Delphi DCM7.1A BSL (FID: 264) [SM2 Only] [TEST]

PSA Continental SID208 (FID: 232)

PSA Bosch EDC17C10 TC1797 (FID: 210)

PSA Bosch EDC17C10 TC1796 (FID: 211)

PSA Bosch EDC17C60 TC1793 (FID: 212)

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

FID: 179, 210, 211, 232, 264

Module for reading and writing Delphi ECUs used in Peugeot and Citroen diesel vehicles.

PSA Delphi DCM6.2A (FID: 179)

This ECU is based on MCU NXP MPC5674 with internal flash memory 4.0 Mb. Allows reading and writing of calibration area by OBD2 with checksum correction on writing.

PSA Delphi DCM7.1A BSL (FID: 264) [SM2 Only] [TEST]

This ECU is based on MCU Aurix TC297 with internal flash memory 6.0 Mb. Allows reading and writing of FullFlash in BSL mode with checksum correction on writing. Work only with Scanmatik 2 J2534 adapter.

PSA Continental SID208 (FID: 232)

ECU is based on MCU Infineon Tricore TC1797 with internal flash memory 4.0 Mb. Allows reading and writing of calibration area by OBD2 with checksumm correction on writing. Work only with Scanmatik SM2/SM2 Pro and OpenPort 2.0.

PSA Bosch EDC17C10 TC1797 (FID: 210)

ECU is based on MCU Infineon Tricore TC1797 with internal flash memory 4.0 Mb. Allows reading and writing of calibration area by OBD2 with checksumm correction on writing.

PSA Bosch EDC17C10 TC1796 (FID: 211)

ECU is based on MCU Infineon Tricore TC1796 with external flash memory 4.0 Mb. Allows reading and writing of calibration area by OBD2 with checksumm correction on writing.

PSA Bosch EDC17C60 TC1793 (FID: 212)

ECU is based on MCU Infineon Tricore TC1793 with internal flash memory 4.0 Mb. Allows reading and writing of calibration area by OBD2 with checksumm correction on writing.

PSA Valeo V46.11 (FID: 346)

PSA Valeo VD46.1 (FID: 347)

PSA Bosch MEV17.4 (FID: 360)

PSA Bosch MEV17.4.2 (FID: 364)

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

FIDs: 346, 347, 360, 364

Module for reading and writing ECUs by CANbus used in Peugeot and Citroen petrol vehicles.

PSA Valeo V46.11 (FID: 346)

ECU is based on MCU Renesas SH72543 with internal flash memory 2.0 Mb. Allows reading and writing of calibration area by OBD2 with checksumm correction on writing.

PSA Valeo VD46.1 (FID: 347)

ECU is based on MCU Renesas SH72546 with internal flash memory 3.75 Mb. Allows reading and writing of calibration area by OBD2 with checksumm correction on writing.

PSA Bosch MEV17.4 (FID: 360)

ECU is based on MCU Tricore TC1766 with internal flash memory 1.46 Mb. Allows reading and writing OBD2 with checksumm correction on writing.

PSA Bosch MEV17.4.2 (FID: 364)

ECU is based on MCU Tricore TC1767 with internal flash memory 2.0 Mb. Allows reading and writing OBD2 with checksumm correction on writing.

Other ECU types will be added ASAP. Module license cost can be changed in future.

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

FID: 51, 52, 53, 54, 55, 56, 58, 59, 61, 86, 146, 158, 408

Software module for reading and writing Delphi ECUs internal flash memory for China vehicles with petrol engines.

• Delphi MT20U (FID: 51) with Motorola MC912DT128 128Kb - R/W/CS
• Delphi MT20U2 (FID: 59) with Motorola MC9S12KG256 256Kb - R/W/CS
• Delphi MT22.1 (FID: 52) with Motorola MC9S12XEP768 768Kb - R/W/CS
• Delphi MT22.1 IAC (FID: 158) with Motorola MC9S12XEQ512 512Kb - R/W/CS
• Delphi MT22U (FID: 53) with Motorola MC9S12XET256 256Kb - R/W/CS
• Delphi MT20UED (FID: 58) with Motorola MC9S12KG256 256Kb - R/W/CS
• Delphi MT22.1.1 HW1 (FID: 54) with Motorola MC9S12XET256 256Kb - R/W/CS
• Delphi MT34 (FID: 55) with Infineon Tricore + EXT.Flash 1Mb - R/W/noCS - test
• Delphi MT62.1 K-line (FID: 56) with NXP SPC5634 1.5Mb - R/W/noCS
• Delphi MT62.1 CAN (FID: 146) with NXP SPC5634 1.5Mb - R/W/noCS
• Delphi MT62.1 JAC CAN (FID: 408) with NXP SPC5634 1.5Mb - R/W/noCS
• Delphi MT80 (FID: 61) with Infineon Tricore TC1762 1.5Mb - R/W/CS

Delphi MT92/MT92.1 (FID: 86) with Infineon Tricore TC17xx 2Mb/2.5Mb - R/W/noCS - test

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

FID: 57, 60, 63, 68, 75, 76, 81, 82, 84, 127, 233, 234, 239, 338

Software module for reading and writing Bosch ECUs internal flash memory for China vehicles with petrol engines.

• Bosch M7.9.7 (FID: 239) with C167 512kb VR/W/CS
• Bosch ME7.9.7 (FID: 68) with C167 1Mb VR/W/CS
• Bosch ME7.9.7 (FID: 68) with C167 1Mb VR/W/CS
• Bosch M(E)7.9.71 (FID: 233) with ST10F275 832Kb VR/W/CS
• Bosch M7.8 (FID: 57) with ST10F275 832Kb VR/W/CS
• Bosch M7.8.17 FAW (FID:414) SPC563 1.5MB R/W/CS
• Bosch ME7.8.8 (FID: 63) with ST10F275 832Kb K-line VR/W/CS
• Bosch ME7.8.8 (FID: 76) with ST10F275 832Kb CAN VR/W/CS
• Bosch ME17.8.8 (FID: 60) with Infineon TC1728 1.5Mb R/W/CS
• Bosch ME17.8.8 Saic (FID: 127) with Infineon TC1728 1.5Mb R/W/CS
• Bosch ME17.8.8 Vantage (FID: 166) with Infineon TC1728 1.5Mb R/W/CS
• Bosch ME17.8.8.1 (FID: 82) with Infineon TC1728 1.5Mb R/W/CS
• Bosch ME17.8.8.1 Geely (FID: 84) with Infineon TC1728 1.5Mb R/W/CS
• Bosch MED17.8.10 Haval (FID: 122) with Infineon TC1728 1.5Mb R/W/CS /TEST/
• Bosch MED17.8.10 Geely (FID: 234) with Infineon TC1728 1.5Mb R/W/CS /TEST/
• Bosch MED17.8.10 Chery (FID: 338) with Infineon TC1782 2.5Mb R/W/CS
• BYD TB10 Type1 (FID: 81) with Renesas SH72531 1.25Mb R/W/CS
• BYD TB10 Type2 (FID: 148) with Renesas SH72531 1.25Mb VR/W/CS
• Bosch M7.8/ME7.8.8 BSL (FID: 75) with ST10F275 832Kb K-line R/CS*

* - adapter BITS001 required. Tested only with J2534 Tactrix Openport 2.0

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

FID: 57, 60, 63, 68, 75, 76, 81, 82, 84, 127, 233, 234, 239, 338

Software module for reading and writing Delphi ECUs internal flash memory for China vehicles with diesel engines.

China Delphi DCM3.7AP (FID: 145) This ECU is based on MCU Renesas SH72513 with internal flash memory 2.0 Mb. Allows reading and writing by CANbus with checksumm correction on writing.

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

FIDs: 420, 421, 422, 423, 424, 425, 427, 428, 429, 430, 431, 446

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

FID: 83

Software module for reading and writing Siemens/Continental ECUs internal flash memory for China vehicles with petrol engines.

Continental Simos 9.5 (FID: 83)

ECU Simos 9.5 is based on MCU C167 with external flash memory 512 Kb. It allows to virtual read fullflash, write calibration area via CANbus and checksumm correction on writing.

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

Magneti Marelli IAW 7GV (FID: 5)

Magneti Marelli IAW 7GVE (FID: 71)

Magneti Marelli IAW 9GV (FID: 7)

Magneti Marelli IAW 4HV (FID: 17)

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

FID: 5, 7

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

VAG Continental Simos 18.X (FID: 402)

VAG Continental Simos 18.10 (FID: 403)

VAG Continental Simos PCR2.1 (FID: 411)

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

FID: 401, 402, 403, 406, 410, 411

Porsche Continental EMS SDI4 BENCH-CAN (FID: 432)

Porsche Continental EMS SDI6.X BENCH-CAN (FID: 433)

Porsche Continental EMS SDI8 BENCH-CAN (FID: 434)

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

GM Bosch EDC16C39 HW1 (FID: 65)

GM Bosch EDC16C39 HW2 (FID: 67) - Bench OBD only

GM ACDelco E87 (FID: 90)

GM ACDelco E98 (FID: 85)

GM Delphi DCM3.7AP (FID: 317)

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

GM ACDelco E38 (FID: 96)

GM ACDelco E39 (FID: 100)

GM ACDelco E39A (FID: 97)

GM ACDelco E67 (FID: 99)

GM ACDelco E78 (FID: 94)

GM ACDelco E80 (FID: 102)

GM ACDelco E83 (FID: 91)

GM ACDelco E92 (FID: 98)

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

GM ACDelco E39A Gen2 (FID: 129)

GM ACDelco E78 Gen2 (FID: 231)

GM ACDelco E80 Gen2 (FID: 176)

GM ACDelco E82 Gen2 (FID: 168)

GM ACDelco E84 Gen2 (FID: 167)

GM ACDelco E92 Gen2 (FID: 128)

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

FID: 109, 110, 112, 113, 114, 115, 116, 119

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

FID: 117, 118

DAF/Industrial Delphi ETC3 (FID: 220)

Hyundai Delphi ETC3 (FID: 221)

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

Scania Continental EMS S8/EMD1 (FID: 404)

Scania Motorola EMS S7 (FID: 405)

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

Features of Module:

• Identification
• Reading calibration
• Writing calibration
• Checksum calculation

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

FID: 2

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

FID: 337

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

FIDs: 191, 192, 193, 194, 195, 196

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

FIDs: 228, 229

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

FIDs: 125, 126, 174, 175, 226, 227

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

FID: 30, 43

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

FID: 10, 11, 31, 36, 80, 199

Bosch MSE3.0 (FID: 6, 78)

Bosch MSE6.0/US6.0 (FID: 79)

Bosch MSE8.0 (FID: 413)

Bosch ME17.8.10 (FID: 416)

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

FID: 6, 78, 79, 413, 416

MV Agusta Eldor EM2.0 (FID:120)

Beta Eldor MCU3.0 (FID:354)

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

FID: 170, 171, 172

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

FID: 64, 103

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

FID: 198

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

FIDs: 341, 357

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

Caption:

RD: Read

VR: Vitual Reading

WR: Write

CS: Checksums and CVN correction

R: Recovery

UNLOCK: Unlock ECU

FIDs: 348, 362

Module for reading and writing ECUs by CANbus used in Lada/VAZ/UAZ petrol vehicles.

VAZ M86 (FID: 348)

ECU is based on MCU Infineon XC27XX with internal flash memory 1088Kb. Allows virtual reading and writing of calibration area by OBD2 with checksum correction on writing.

VAZ M86I (FID: 362)

ECU is based on MCU Infineon XC2XXX with internal flash memory 1088Kb. Allows virtual reading and writing of calibration area by OBD2 with checksum correction on writing.

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

FIDs: 142, 143, 305, 306, 307, 308, 309, 310, 311, 312, 313, 314, 315, 316, 349, 353, 355, 356, 359, 361, 370

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

Caption:

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU

Universal module for bench reading and writing for Bosch ME(D)17 and EDC17 ECUs based on Infineon TC17xx. FID: 407

Allows reading and writing flash and EEPROM on the bench with auto detection of MCU type and file size by using Bosch Service Mode (BSM). Checksum fix is performed on writing. ECU opening is not needed. Connection is only on the bench.

Supported MCUs: TC1724, TC1728, TC1762, TC1766, TC1767, TC1782, TC1792, TC1793, TC1796, TC1797
Supported ECUs: Click to see list of supported ECUs

New ECUs support will be added.

Attention! Read before purchasing:

Module works only with Scanmatik SM2 or SM2 Pro.
This FID is not suitable for cloning ECU because there are protected OTP sectors. Also sectors (0x10; 0x20) are skipped during writing operation in order to avoid bricking ECUs.
On some ECUs checksums calculation may take a long time. It depends on the configuration of your computer.
In case of an identification error, check your connection, and also change the places of the GPT wire.
All tested adapters with automatic power management with wires for the GPT signal output available

• RD: Read
• VR: Vitual Reading
• WR: Write
• CS: Checksums and CVN correction
• R: Recovery
• UNLOCK: Unlock ECU
